Overview
| Models: | Aveo 4-door sedan |
| Body style / driveline: | 4-door unitized frame (monocoque), front engine, front-wheel drive, 5 passengers |
| Construction: | steel body material, galvanized |
| EPA vehicle class: | subcompact |
| Manufacturing location: | Bupyong, South Korea |
| Key competitors: | Hyundai Accent, Kia Rio, Honda Fit, Toyota Yaris |
Engine
Type: | 1.6L DOHC I-4 |
Displacement (cu in / cc): | 97.5 / 1598 |
Bore & stroke (in / mm): | 3.11 x 3.21 / 79 x 81.5 |
Block material: | cast iron |
Cylinder head material: | aluminum |
Valvetrain: | DOHC, 4 valves per cylinder |
Fuel delivery: | multi-port fuel injection |
Compression ratio: | 9.5:1 |
Horsepower (hp / kW @ rpm): | 103 / 77 @ 5800* |
Torque (lb-ft / Nm @ rpm): | 107 / 145 @ 3400* |
Recommended fuel: | 87 octane |
Maximum engine speed (rpm): | auto: 6500 man. 5250 |
Emission controls: | catalytic converter / Delphi EMS |
Estimated fuel economy | |
(mpg city / hwy): | auto: 26 / 34 man: 27 / 35 |
Transmissions
| Manual | Automatic | |
| Type: | 5-speed manual with overdrive, front-wheel drive | 4-speed Aisin automatic with overdrive, front-wheel drive |
| Gear ratios (:1): | ||
| First: | 3.55 | 2.88 |
| Second: | 1.95 | 1.57 |
| Third: | 1.28 | 1.00 |
| Fourth: | 0.97 | 0.70 |
| Fifth: | 0.76 | -- |
| Reverse: | 3.33 | 2.30 |
| Final drive ratio: | 3.94 | 3.75 |
Chassis/Suspension
| Front: | MacPherson struts with offset coil springs and 17-mm stabilizer bar |
| Rear: | semi-independent torsion beam axle with coil springs |
| Steering type: | power rack-and-pinion |
| Steering ratio: | 16:1 |
| Steering wheel turns, lock-to-lock: | 3 |
| Turning circle, curb-to-curb (ft / m): | 33.01 / 10.06 |
Brakes
| Type: | ventilated front disc and rear drum, 4-channel ABS optional |
| Rotor diameter x thickness (in / mm): | front: 10.1 x .95 / 256 x 24 |
| Drum diameter x width (in / mm): | rear: 7.8 x 1.38 / 200 x 35 (lining width) |
| Total swept area (sq in / sq cm): | front: 6.98 / 45 rear: 9.3 / 60 |
Wheels/Tires
| Wheel size and type: | 14-inch x 5.5-inch steel with full wheel covers (std on LS); 14-inch x 5.5-inch aluminum alloy wheels (opt on LS) |
| 15-inch x 6-inch aluminum alloy (std on LT) | |
| Tires: | P185/60R14 all-season touring (std on LS) |
| P185/55R15 all-season touring (std on LT) |
Dimensions
Exterior
| Wheelbase (in / mm): | 97.6 / 2480 |
| Overall length (in / mm): | 169.7 / 4310 |
| Overall width (in / mm): | 67.3 / 1710 |
| Overall height (in / mm): | 59.2 / 1505 |
| Track (in / mm): | front: 57.1 / 1450 rear: 56.3 / 1430 |
| Curb weight (lb / kg): Automatic: Manual: | 2542 / 1153 2531 / 1148 |
Interior
| Seating capacity (front / rear): | 2 / 3 |
| Headroom (in / mm): | front: 39.3 / 998; rear: 37.4 / 950 |
| Legroom (in / mm): | front: 41.3 / 1048; rear: 35.4 / 898 |
| Shoulder room (in / mm): | front: 53.6 / 1362; rear: 52.8 / 1340 |
| Hip room (in / mm): | front: 51.6 / 1310; rear: 52.8 / 1340 |
Capacities
| EPA interior volume (cu ft / L): | 90.7 / 2568 |
| Cargo volume (cu ft / L): | 12.4 / 351 |
| Fuel tank (gal / L): | 11.9 / 45 |
| Engine oil (qt / L): | 4 / 3.75 |
| Cooling system (qt / L): | 6.34 / 6 |
* A new voluntary power and torque certification procedure developed by the SAE Engine Test Code committee was approved March 31, 2005. This procedure (J2723) ensures fair, accurate ratings for horsepower and torque by allowing manufacturers to certify their engines through third-party witness testing. GM was the first auto manufacturer to begin using the procedure and expects to use it for all newly rated engines in the future.
1 | 2 | 3 | 4
